HiTEC® 12204L – HDEO Additive Package

HiTEC® 12204L is a high-performance heavy-duty diesel engine oil (HDEO) additive package developed as part of Afton’s 12200 product family. It is engineered to meet the demands of modern diesel engines operating under severe conditions, including vehicles equipped with EGR systems and fleets running in harsh environments, heavy loads, low-quality fuel, and extreme climates.

Formulated to enable the blending of lubricants meeting API CI-4 Plus SAE 15W-40, HiTEC® 12204L delivers exceptional soot handling, wear protection, oxidation resistance, and deposit control. It ensures stable viscosity throughout the drain interval, extends engine life, and maintains power by preventing harmful sludge and piston deposits. The product has been field-tested in demanding real-world conditions and has demonstrated the capability to support extended oil drain intervals up to 50,000 km depending on field conditions and OEM guidance.

Key Performance Benefits

• Outstanding soot handling performance for engines with EGR systems
• Superior wear protection, including ring/liner and bearing protection
• Excellent piston cleanliness and deposit control
• Strong oxidation stability for prolonged lubricant life
• Helps maintain engine power over extended service intervals
• Proven capability for long oil drains under harsh operating conditions
• Broad base oil compatibility across common API Group II and Group III base stocks

Applications

• Heavy-duty diesel engines operating in severe environments
• Trucks, buses, off-road machinery, and construction equipment
• Engines requiring API CI-4 Plus performance
• Suitable for blending SAE 15W-40 formulations using approved viscosity modifiers and base stocks
• Fleets operating in challenging conditions such as poor roads, extreme temperatures, and low-quality fuel

Recommended Dosage

• 14.2 wt% to achieve API CI-4 Plus SAE 15W-40 performance levels.

Typical Characteristics

• Density, lbs/gal: 8.11
• Specific Gravity @ 15.6°C: 0.972
• Viscosity @ 100°C: 190 cSt
• Flash Point (PMCC): 135°C min
• Total Base Number (TBN): 82 mg KOH/g

Handling & Storage

• Maximum handling temperature: 70°C
• Shelf life:
  • 3 months at 45°C
  • 36 months at ambient temperature (10–40°C)
• Store in a dry, clean, well-ventilated warehouse.
• Standard safety procedures for petroleum additives apply.
